TFV
CARBON MONOCOQUE UD
L'immagine è solo a scopo illustrativo. Per tutte le specifiche e gli allestimenti consultare il rivenditore.
SIZE
S – M – L – XL
Frame kit available
WEIGHT
1470 gr
Carbon, raw frame weight, size M
490 gr
Carbon, raw fork weight
150 gr
Carbon, raw seat post weight
Scorri la tabella →
| GEOMETRY | S | M | L | XL | |
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (mm) | 515 | 520 | 540 | 550 |
| RC | CHAIN STAY LENGTH (mm) | 395 | 395 | 395 | 395 |
| C | HEAD TUBE ANGLE (mm) | 72,5 | 72,5 | 72,5 | 72,5 |
| D | HEAD TUBE LENGTH (mm) | 95 | 100 | 120 | 130 |
| E | SEAT TUBE ANGLE (°) | 76 | 76 | 76 | 76 |
| F | TOP TUBE HORIZONTAL (mm) | 510 | 530 | 550 | 570 |
| FC | FRONT CENTRE (mm) | 570 | 590 | 612 | 632 |
| WB | WHEELBASE (mm) | 956 | 976 | 997 | 1018 |
| DROP | BOTTOM BRACKET DROP (mm) | 68 | 68 | 68 | 68 |
| STACK | STACK (mm) | 497 | 501 | 520 | 530 |
| REACH | REACH (mm) | 386 | 404 | 420 | 438 |
